Jinan Bodor CNC Machine Co., Ltd.

High quality low noise laser engraving machine
High quality low noise laser engraving machine
High quality low noise laser engraving machine
High quality low noise laser engraving machine
High quality low noise laser engraving machine

High quality low noise laser engraving machine

Add to Basket

Basic Info

    Model No.: BCL-MU

Product Description

Brief Introduction

laser engraving cutting machine is to give full play to the movement control performance and enhance the laser processing effect, from software design, mechanical structure, electrical performance to the accessories selection, always stressed the purpose of processing site services, in a comprehensive quality management system factory environment Under the production operations, stability, accuracy and speed of the three indicators can reflect the world-class equipment standards. Excellence in the products, as the industrial site of the new means of operation - the best carrier of laser processing.

China high quality low noise Laser Engraving Machine,When the working current is 4mA and the tube is in the state of pre-ionization, the laser can be used for high-frequency impulse engraving. Mini Laser Engraving And Cutting Machine can cut many materials,such as acrylic,wood planks,bamboo ware,double color board,paper,leather,shell,coconut,shell,ABS board,etc.

Smart size Easy to put and work.
3 in 1 closed beam simple and generous.
150mm stainless steel up and down table with ball screw,Higher accuracy.
"Big eye" design,Transparent acrylic window,easy to view.
Turn off the power to continue engraving. Open cover with protection.
Stainless steel hollow table,Eject smoke well,never rust.
Up-down work table,use ball screw transmission system.
High-efficiency laser tube,excellent laser beam long life time 4000-10000hours.
Professional control system.

Technical Parameter
Model BCL0503MU BCL0605MU
Working Area 500*300mm 600*500mm
Laser Power 40W 40W/80W
Laser Type CO2 Sealed Laser Tube, 10.6μm
Cooling Type Water Cooling
Engraving Speed 0-60000mm/min
Cutting Speed 0-40000mm/min
Laser Output Control (0-100% Set by Software )
Min. Engraving Size Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm
Highest Scanning Precision 4000DPI
Locating Precision ≤+0.01mm
Controlling Software DSP Control System
Graphic Format Supported DST PLT BMP DXF DWG AI LAS,etc
Color Separation Yes
Drive System High-precision 3-phase Stepper Motor
Auxiliary Equipments Exhaust Fan and Air Exhaust Pipe
Power Supply AC110V/220V+10%,50HZ/60HZ
Working Environment Temperature:0-45℃,Humidity 5-95%(No Condensate Water)

Optional Spare Parts Honeycomb Worktable, Rotary Device,Auto-focus Device

High quality low noise laser engraving machine

Product Categories : Laser Engraving Machine > Mini Laser Engraving Machine
